9070210252003
7021 025.200
|
25.20 mm SOLID CARBIDE ROD UNGROUND DK120/GC060F (6% Co, 1.3µm) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9070210262003
7021 026.200
|
26.20 mm SOLID CARBIDE ROD UNGROUND DK120/GC060F (6% Co, 1.3µm) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9070220092003
7022 009.200
|
9.20 mm SOLID CARBIDE ROD UNGROUND DK255F/GC080S (8% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9070140352003
7014 035.200
|
35.20 mm SOLID CARBIDE ROD UNGROUND DK460UF/GC100S (10% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9070320090004
7032 009.000
|
9.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9071470040004
7147 004.000
|
4.00 mm SOLID CARBIDE ROD GROUND h6 GC100SX / K40XF (10% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9070320130004
7032 013.000
|
13.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9070320140004
7032 014.000
|
14.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9073190030004
7319 003.000
|
3.00 mm SOLID CARBIDE ROD GROUND h6 K6UF/GC060S (6% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9073190252003
7319 025.200
|
25.20 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9073300100004
7330 010.000
|
10.00mm x 136mm OAL 2 COOLANT DUCTS 40º HELIX 3.50 mm B.C. 0.80 mm DUCT DIA. 37.44 mm PITCH CARBIDE ROD, GROUND h6 Tol. DK460UF/GC100S(10% Co.) Fixed Length (From 7935 010.300 Actual Lead: Avg 37.67mm)
|
|
hidden
|
hidden
|
hidden
|
|
9073300120014
7330 012.001
|
12.00 mm 2 COOLANT DUCTS 40º HELIX 2.50 mm B.C. 0.60 mm DUCT DIA. 44.93 mm PITCH CARBIDE ROD, GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9072000063504
7200 006.350
|
(1/4") 6.350 MM x 71.2 MM OAL Solid Carbide Blank Ground to h6 Tol. K6UF/GC060S (6% Co.) Fixed Length W/ Chamfer 1 End
|
|
hidden
|
hidden
|
hidden
|
|
9072000063514
7200 006.351
|
(1/4") 6.350 MM x 64.7 MM OAL Solid Carbide Blank Ground to h6 Tol. K6UF/GC060S (6% Co.) Fixed Length W/ Chamfer 1 End
|
|
hidden
|
hidden
|
hidden
|
|
9073110250004
7311 025.000
|
25.00 mm SOLID CARBIDE ROD GROUND h6 K44UF/GC120U (12% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9073110252003
7311 025.200
|
25.20 mm SOLID CARBIDE ROD UNGROUND K44UF/GC120U (12% Co.) OAL 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
9073890031503
7389 003.150
|
D 3.150 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT WDR: 0.84 mm
(9073890031503)
|
|
hidden
|
hidden
|
hidden
|
|
9073890031523
7389 003.152
|
D 3.150 mm X L 200 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT WDR: 0.84 mm
(9073890031523)
|
|
hidden
|
hidden
|
hidden
|
|
9073890013023
7389 001.302
|
D 1.300 mm X L 200 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.14MM / PERMITTED TWIST: 4 Deg. (9073890013023)
|
|
hidden
|
hidden
|
hidden
|
|
9075400100124
7540 010.012
|
10.00 mm x 84.00 mm OAL MILLING CUTTER BLANK METRIC DIAM. CHAMFERED ONE END GROUND h6 DK 460UF FIX LENGTH
|
|
hidden
|
hidden
|
hidden
|
|
9079150250004
7915 025.000
|
25.00 mm x 150.0 mm OAL; 2 Coolant Ducts 30º Helix; Ground to h6 Tol; BC 12.00 mm; d 2.50 mm; Pitch 136.03 mm; 120º point on one end; Chamfered and Slotted on Back End DK460UF/GC100S (10% Co)
|
|
hidden
|
hidden
|
hidden
|
|
9079160250004
7916 025.000
|
25.00 mm x 169.0 mm OAL; 2 Coolant Ducts 30º Helix; Ground to h6 Tol; BC 12.00 mm; d 2.50 mm; Pitch 136.03 mm; 120º point on one end; Chamfered and Slotted on Back End DK460UF/GC100S (10% Co)
|
|
hidden
|
hidden
|
hidden
|
|
9079340133003
7934 013.300
|
13.30 mm 3 COOLANT DUCTS 40º HELIX 4.40 mm B.C. 0.90 mm DUCT DIA. 48.67 mm PITCH SOLID CARB. UNGROUND DK460UF 330 mm
|
|
hidden
|
hidden
|
hidden
|
|
303697780LD
3036
|
[12XD] 12.00mm x 204.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 6.25 mm; d 1.55 mm; Pitch 65.30 mm; DK460UF (10% Co) Includes Chamfer 1 End & 1 Flat End [Max Runout: 0.033]
|
|
hidden
|
hidden
|
hidden
|
|
303697781LD
3036
|
[12XD] 12.00mm x 204.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 6.25 mm; d 1.55 mm; Pitch 140.70 mm; DK460UF (10% Co) Includes Chamfer 1 End & 1 Flat End [Max TIR: 0.033]
|
|
hidden
|
hidden
|
hidden
|
|
303697797LD
LONG DRILL BLANKS
|
[16XD] 10.00mm x 225.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 4.80 mm; d 1.40 mm; Pitch 54.41 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.044]
|
|
hidden
|
hidden
|
hidden
|
|
303697799LD
LONG DRILL BLANKS
|
[16XD] 12.00mm x 265.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 6.25 mm; d 1.55 mm; Pitch 65.30 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.043]
|
|
hidden
|
hidden
|
hidden
|
|
303697807LD
LONG DRILL BLANKS
|
[20XD] 6.00mm x 185.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 2.20 mm; d 0.70 mm; Pitch 32.65 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697810LD
LONG DRILL BLANKS
|
[20XD] 8.00mm x 230.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 3.60 mm; d 1.25 mm; Pitch 43.53 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.045]
|
|
hidden
|
hidden
|
hidden
|
|
303697812LD
LONG DRILL BLANKS
|
[20XD] 10.00mm x 290.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 4.80 mm; d 1.40 mm; Pitch 54.41 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.056]
|
|
hidden
|
hidden
|
hidden
|
|
303697813LD
LONG DRILL BLANKS
|
[20XD] 10.00mm x 290.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 4.80 mm; d 1.40 mm; Pitch 117.2 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.056]
|
|
hidden
|
hidden
|
hidden
|
|
303697814LD
LONG DRILL BLANKS
|
[20XD] 12.00mm x 315.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 6.25 mm; d 1.55 mm; Pitch 65.30 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.050]
|
|
hidden
|
hidden
|
hidden
|
|
303697816LD
LONG DRILL BLANKS
|
[20XD] 14.00mm x 355.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 6.70 mm; d 1.90 mm; Pitch 76.18 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.030]
|
|
hidden
|
hidden
|
hidden
|
|
303697820LD
LONG DRILL BLANKS
|
[25XD] 6.00mm x 205.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 2.20 mm; d 0.70 mm; Pitch 32.65 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.066]
|
|
hidden
|
hidden
|
hidden
|
|
303697821LD
LONG DRILL BLANKS
|
[25XD] 6.00mm x 180.00 mm OAL; Ground to h6 Tol; 2 Hole 22° Helix; BC 1.90 mm; d 0.60 mm; Pitch 46.90 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.058]
|
|
hidden
|
hidden
|
hidden
|
|
303697822LD
LONG DRILL BLANKS
|
[25XD] 6.00mm x 205.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 2.60 mm; d 0.70 mm; Pitch 70.35 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.050]
|
|
hidden
|
hidden
|
hidden
|
|
303697823LD
LONG DRILL BLANKS
|
[25XD] 8.00mm x 260.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 3.60 mm; d 1.30 mm; Pitch 43.53 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.050]
|
|
hidden
|
hidden
|
hidden
|
|
303697824LD
LONG DRILL BLANKS
|
[25XD] 8.00mm x 260.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 3.60 mm; d 1.30 mm; Pitch 93.80 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.050]
|
|
hidden
|
hidden
|
hidden
|
|
303697825LD
LONG DRILL BLANKS
|
[25XD] 10.00mm x 310.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 4.80 mm; d 1.40 mm; Pitch 54.41 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697826LD
LONG DRILL BLANKS
|
[25XD] 10.00mm x 310.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 4.80 mm; d 1.40 mm; Pitch 117.20 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697827LD
LONG DRILL BLANKS
|
[25XD] 12.00mm x 375.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 6.25 mm; d 1.55 mm; Pitch 65.30 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697829LD
LONG DRILL BLANKS
|
[30XD] 6.00mm x 185.00 mm OAL; Ground to h6 Tol; 2 Hole 46° Helix; BC 1.60 mm; d 0.50 mm; Pitch 18.00 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697830LD
LONG DRILL BLANKS
|
[30XD] 6.00mm x 215.00 mm OAL; Ground to h6 Tol; 2 Hole 40° Helix; BC 1.90 mm; d 0.70 mm; Pitch 22.50 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.069]
|
|
hidden
|
hidden
|
hidden
|
|
303697833LD
3036
|
[30XD] 6.00mm x 230.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 2.60 mm; d 0.70 mm; Pitch 70.35 mm; DK460UF (10% Co) Includes 1 Flat End & Chamfer 1 End [Max TIR 0.074]
|
|
hidden
|
hidden
|
hidden
|
|
303697834LD
LONG DRILL BLANKS
|
[30XD] 8.00mm x 315.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 3.60 mm; d 1.25 mm; Pitch 43.53 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697835LD
LONG DRILL BLANKS
|
[30XD] 8.00mm x 315.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 3.60 mm; d 1.25 mm; Pitch 93.80 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697836LD
LONG DRILL BLANKS
|
[30XD] 10.00mm x 380.00 mm OAL; Ground to h6 Tol; 2 Hole 30° Helix; BC 4.80 mm; d 1.4 mm; Pitch 54.41 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.074]
|
|
hidden
|
hidden
|
hidden
|
|
303697837LD
LONG DRILL BLANKS
|
[30XD] 10.00mm x 380.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 4.80 mm; d 1.40 mm; Pitch 117.20 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.074]
|
|
hidden
|
hidden
|
hidden
|
|
303697839LD
LONG DRILL BLANKS
|
[30XD] 12.00mm x 375.00 mm OAL; Ground to h6 Tol; 2 Hole 15° Helix; BC 6.25 mm; d 1.55 mm; Pitch 140.70 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.060]
|
|
hidden
|
hidden
|
hidden
|
|
303697840LD
LONG DRILL BLANKS
|
[40XD] 6.00mm x 230.00 mm OAL; Ground to h6 Tol; 2 Hole 46° Helix; BC 1.60 mm; d 0.50 mm; Pitch 18.00 mm; DK460UF (10% Co) Includes Chamfer 1 End [Max Runout: 0.074]
|
|
hidden
|
hidden
|
hidden
|
