COOLANT THROUGH RODS

3x, 5x, 8xD, GROUND h6, UNGROUND, IMPERIAL 1/8in. - 1in., 6mm - 25mm DIA, Cut to Length, 120° POINT, COOLANT SLOT, CHAMFERED

Browse By Product Groups

1 CENTRAL DUCT GROUND DRILL ROD

2 COOLANT DUCTS 15° HELIX GROUND DRILL ROD

2 COOLANT DUCTS 30º HELIX GROUND DRILL ROD

2 COOLANT DUCTS 40º HELIX GROUND DRILL ROD

2 PARALLEL DUCTS STRAIGHT GROUND DRILL ROD

3 COOLANT DUCTS 30º HELIX GROUND DRILL ROD

3 COOLANT DUCTS 40º HELIX GROUND DRILL ROD

SOLID GROUND ROD

Material To Machine

Application

Diameter (MM)

Diameter (inch)

Diameter (frac)

Carbide Grade

Overall Length (mm)

Overall Length (inch)

Ground / Unground

Helix Angle

Pitch

Series

Order Code

ItemNo

Steel

338 items

Stainless Steel

351 items

Grey cast iron, malleable, and spheroidal iron

326 items

Aluminium and other non-ferrous metal

326 items

Special, super and titanium alloys

338 items

Hardened steel and chilled cast iron

13 items

Results 1-50 of 351

EDP: 9073300120014

Series: 7330
Code: 012.001

12.00 mm 2 COOLANT DUCTS 40º HELIX 2.50 mm B.C. 0.60 mm DUCT DIA. 44.93 mm PITCH CARBIDE ROD, GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

EDP: 9071470040004

Series: 7147
Code: 004.000

4.00 mm SOLID CARBIDE ROD GROUND h6 GC100SX / K40XF (10% Co.) OAL 330 mm

EDP: 9073190120004

Series: 7319
Code: 012.000

12.00 mm SOLID CARBIDE ROD GROUND h6 K6UF/GC060S (6% Co.) OAL 330 mm

EDP: 9073190160004

Series: 7319
Code: 016.000

16.00 mm SOLID CARBIDE ROD GROUND h6 K6UF/GC060S (6% Co.) OAL 330 mm

EDP: 9073190252003

Series: 7319
Code: 025.200

25.20 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

EDP: 9070320090004

Series: 7032
Code: 009.000

9.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm

EDP: 9070320130004

Series: 7032
Code: 013.000

13.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm

EDP: 9070320140004

Series: 7032
Code: 014.000

14.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm

EDP: 9073890013023

Series: 7389
Code: 001.302

D 1.300 mm X L 200 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.14MM / PERMITTED TWIST: 4 Deg. (9073890013023)

EDP: 9073890031503

Series: 7389
Code: 003.150

D 3.150 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT WDR: 0.84 mm (9073890031503)

EDP: 9073890031523

Series: 7389
Code: 003.152

D 3.150 mm X L 200 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT WDR: 0.84 mm (9073890031523)

EDP: 9070750010004

Series: 7075
Code: 001.000

1.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
1 mm	0.0394"	330 mm	12.9921"

EDP: 9073890013003

Series: 7389
Code: 001.300

D 1.300 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.25MM / PERMITTED TWIST: 7 Deg. (9073890013003)

Diameter
1.3 mm	0.0512"

EDP: 9073890015003

Series: 7389
Code: 001.500

D 1.500 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.25MM / PERMITTED TWIST: 7 Deg. (9073890015003)

Diameter
1.5 mm	0.0591"

EDP: 9073890015023

Series: 7389
Code: 001.502

D 1.500 mm X L 200 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.14MM / PERMITTED TWIST: 4 Deg. (9073890015023)

Diameter
1.502 mm	0.0591"

EDP: 9073890017003

Series: 7389
Code: 001.700

D 1.700 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.25MM / PERMITTED TWIST: 7 Deg. (9073890017003)

Diameter		OAL
1.7 mm	0.0669"	350 mm	13.7795"

EDP: 9073890017023

Series: 7389
Code: 001.702

D 1.700 mm X L 200 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT - CONCENTRICITY: 0.14MM / PERMITTED TWIST: 4 Deg. (9073890017023)

Diameter
1.702 mm	0.0670"

EDP: 9073890019003

Series: 7389
Code: 001.900

D 1.900 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT WDR: 0.35 mm (9073890019003)

Diameter		OAL
1.9 mm	0.0748"	350 mm	13.7795"

EDP: 9070750020004

Series: 7075
Code: 002.000

2.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
2 mm	0.0787"	330 mm	12.9921"

EDP: 9073890021003

Series: 7389
Code: 002.100

D 2.100 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT (9073890021003)

Diameter
2.1 mm	0.0827"

EDP: 9073190022003

Series: 7319
Code: 002.200

2.20 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
2.2 mm	0.0866"	330 mm	12.9921"

EDP: 9073890024003

Series: 7389
Code: 002.400

D 2.400 mm X L 350 mm CARBIDE GUN DRILL ROD DK460UF (10% Co.) UNGROUND CONTAINS KINDNEY SHAPED COOLANT DUCT WDR: 0.40 mm (9073890024003)

Diameter		OAL
2.4 mm	0.0945"	350 mm	13.7795"

EDP: 9073940026003

Series: 7394
Code: 002.600

2.60 MM SOLID CARBIDE GUNDRILL WITH KIDNEY SHAPED COOLANT UNGROUND DK460UF (10% Co.) LENGTH 350 MM

Diameter
2.6 mm	0.1024"

EDP: 9073190027003

Series: 7319
Code: 002.700

2.70 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
2.7 mm	0.1063"	330 mm	12.9921"

EDP: 9073940029003

Series: 7394
Code: 002.900

2.90 MM SOLID CARBIDE GUNDRILL WITH KIDNEY SHAPED COOLANT UNGROUND DK460UF (10% Co.) LENGTH 350 MM

Diameter
2.9 mm	0.1142"

EDP: 9070750030004

Series: 7075
Code: 003.000

3.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
3 mm	0.1181"	330 mm	12.9921"

EDP: 9070850030004

Series: 7085
Code: 003.000

3.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 100 mm

Diameter		OAL
3 mm	0.1181"	100 mm	3.9370"

EDP: 9079320031704

Series: 7932
Code: 003.175

(3.175 mm) 1/8'' SOLID CARBIDE ROD IMPERIAL DIAM. GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter
3.175 mm	0.1250"

EDP: 9073190032003

Series: 7319
Code: 003.200

3.20 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
3.2 mm	0.1260"	330 mm	12.9921"

EDP: 9071470032003

Series: 7147
Code: 003.200

3.20 mm SOLID CARBIDE ROD UNGROUND K40XF/GC100SX (10% Co.) OAL 330 mm

Diameter		OAL
3.2 mm	0.1260"	330 mm	12.9921"

EDP: 9073940034503

Series: 7394
Code: 003.450

3.45 MM SOLID CARBIDE GUNDRILL WITH KIDNEY SHAPED COOLANT UNGROUND DK460UF (10% Co.) LENGTH 350 MM

Diameter		OAL
3.45 mm	0.1358"	350 mm	13.7795"

EDP: 9070850035004

Series: 7085
Code: 003.500

3.50 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 100 mm

Diameter		OAL
3.5 mm	0.1378"	100 mm	3.9370"

EDP: 9070750035004

Series: 7075
Code: 003.500

3.50 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
3.5 mm	0.1378"	330 mm	12.9921"

EDP: 9073190037003

Series: 7319
Code: 003.700

3.70 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
3.7 mm	0.1457"	330 mm	12.9921"

EDP: 9073190040004

Series: 7319
Code: 004.000

4.00 mm SOLID CARBIDE ROD GROUND h6 K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
4 mm	0.1575"	330 mm	12.9921"

EDP: 9070750040004

Series: 7075
Code: 004.000

4.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
4 mm	0.1575"	330 mm	12.9921"

EDP: 9070850040004

Series: 7085
Code: 004.000

4.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 100 mm

Diameter		OAL
4 mm	0.1575"	100 mm	3.9370"

EDP: 9073390040004

Series: 7339
Code: 004.000

4.00 mm CARBIDE ROD 1 CENTRAL DUCT 0.60 mm DUCT DIA. GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
4 mm	0.1575"	330 mm	12.9921"

EDP: 9073020040004

Series: 7302
Code: 004.000

4.00 mm 2 PARALLEL DUCTS STRAIGHT DECREASED PITCH CIRCLE 1.80 mm B.C. 0.80 mm DUCT DIA. CARBIDE ROD, GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
4 mm	0.1575"	330 mm	12.9921"

EDP: 9073190042003

Series: 7319
Code: 004.200

4.20 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
4.2 mm	0.1654"	330 mm	12.9921"

EDP: 9071470042003

Series: 7147
Code: 004.200

4.20 mm SOLID CARBIDE ROD UNGROUND K40XF/GC100SX (10% Co.) OAL 330 mm

Diameter		OAL
4.2 mm	0.1654"	330 mm	12.9921"

EDP: 9073940042003

Series: 7394
Code: 004.200

4.20 mm SOLID CARBIDE GUNDRILL WITH KIDNEY SHAPED COOLANT UNGROUND DK460UF (10% Co.) OAL 350 mm

Diameter		OAL
4.2 mm	0.1654"	350 mm	13.7795"

EDP: 9070750045004

Series: 7075
Code: 004.500

4.50 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
4.5 mm	0.1772"	330 mm	12.9921"

EDP: 9073190047003

Series: 7319
Code: 004.700

4.70 mm SOLID CARBIDE ROD UNGROUND K6UF/GC060S (6% Co.) OAL 330 mm

Diameter		OAL
4.7 mm	0.1850"	330 mm	12.9921"

EDP: 9073940047003

Series: 7394
Code: 004.700

4.70 mm SOLID CARBIDE GUNDRILL WITH KIDNEY SHAPED COOLANT UNGROUND DK460UF (10% Co.) OAL 350 mm

Diameter		OAL
4.7 mm	0.1850"	350 mm	13.7795"

EDP: 9079320047604

Series: 7932
Code: 004.762

(4.762 mm) 3/16'' SOLID CARBIDE ROD IMPERIAL DIAM. GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
4.763 mm	0.1875"	330 mm	12.9921"

EDP: 9070320050004

Series: 7032
Code: 005.000

5.00 mm SOLID CARBIDE ROD GROUND TO h6 Tol. DK255F/GC080S (8% Co.) OAL 330 mm

Diameter		OAL
5 mm	0.1969"	330 mm	12.9921"

EDP: 9070750050004

Series: 7075
Code: 005.000

5.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
5 mm	0.1969"	330 mm	12.9921"

EDP: 9070850050004

Series: 7085
Code: 005.000

5.00 mm SOLID CARBIDE ROD GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 100 mm

Diameter		OAL
5 mm	0.1969"	100 mm	3.9370"

EDP: 9073020050004

Series: 7302
Code: 005.000

5.00 mm 2 PARALLEL DUCTS STRAIGHT DECREASED PITCH CIRCLE 2.00 mm B.C. 0.80 mm DUCT DIA. CARBIDE ROD, GROUND h6 Tol. DK460UF/GC100S (10% Co.) OAL 330 mm

Diameter		OAL
5 mm	0.1969"	330 mm	12.9921"
